Approach

Sickle cell anemia is usually diagnosed by neonatal screening.

Diagnosis is uncommon in childhood or adulthood, although it may occur. Most presentations to primary care physicians or hospitals are for complications. The most common complication is the vaso-occlusive crisis (also known as a painful crisis). The complication that frequently causes death in adults and children is acute chest syndrome.

Diagnosis includes blood tests and genetic tests. If there are existing genetic test results, do not order a duplicate test unless there is uncertainty about the existing result, for example the result is inconsistent with the patient’s clinical presentation or the test methodology has changed.[17]​ Also, do not repeat hemoglobin electrophoresis in patients who have a prior result, unless the results of interventional therapies or hemoglobin levels are being monitored.[18]

Prenatal diagnosis

When both parents carry the recessive sickle cell gene, there is a 1 in 4 chance that their offspring will inherit two recessive alleles, causing sickle cell anemia.

Counseling and prenatal diagnosis may be considered if both parents are either carriers or affected by sickle cell disease (or the woman is a carrier or affected and the status of the father is unknown). Available tests for patients who are pregnant include chorionic villus sampling (typically performed at 10-12 weeks' gestation in the US; 11-14 weeks' gestation in the UK) and amniocentesis (typically performed after 15 weeks' gestation).[19][20]​ These are invasive tests and carry a risk of fetal loss.

Noninvasive prenatal testing (NIPT) of cell-free fetal DNA in maternal circulation is emerging as a potential prenatal screening test for hemoglobinopathies such as sickle cell disease and thalassemia.[13]

Diagnosis in neonates

The primary method by which neonates are diagnosed in the US is a screening program. All states practice universal neonatal screening to ensure that all infants with sickle cell disease are identified.[21]​ Blood for screening is usually taken by heel-stick sample (within 48 hours of birth) and hemoglobin evaluation carried out (ideally within 24 hours of collection).[22][23]

Newborn screening is typically performed using hemoglobin isoelectric focusing (Hb IEF) or high-performance liquid chromatography (HPLC) fractionation. Confirmatory testing should be performed by an alternative method (IEF, HPLC, electrophoresis, or DNA sequencing); timely confirmation is important (no later than age 3 months) to ensure prompt initiation of antibiotic prophylaxis.[24][25]​​

DNA testing is highly accurate and often used for confirming an abnormality found by hemoglobin studies. It may be used in place of hemoglobin studies in some screening programs.[25][26][27][28]​​​​

Diagnosis in infants

Infants do not usually manifest any signs and symptoms until they are 6 months old. However, very young infants with sickle cell disease not diagnosed by the screening program may present with signs and symptoms of hemolysis (jaundice, pallor, or tachycardia) or splenic sequestration crisis (pallor, tachycardia, or shock).

From about age 4 months onward, infants usually present with findings of:

  • Swelling of the joints, especially dactylitis [Figure caption and citation for the preceding image starts]: Hand-foot syndrome in patient age 14 months with homozygous sickle cell diseaseFrom: Davies SC, Oni L. BMJ. 1997 Sep 13;315(7109):656-60 [Citation ends].com.bmj.content.model.Caption@34df4a44

  • Leukocytosis in the absence of infection (the cause is not clear but is suggested to be due to splenic infarction)

  • Protuberant abdomen (due to an enlarged spleen), often with umbilical hernia

  • Cardiac systolic flow murmur secondary to anemia

  • Maxillary hypertrophy with overbite due to extramedullary hematopoiesis, which occurs in some forms of the disease

Additionally, parents may report that their infant has been inconsolable for a long period of time, has been refusing bottles, and has needed fewer diaper changes during the previous 2 days.

The diagnosis is made using Hb IEF. Hemoglobin solubility testing is not recommended in infants ages under 6 months because the high proportion of fetal hemoglobin in relation to adult sickle cell hemoglobin in a newborn's blood may affect the results.

Diagnosis in children

If a child has not been diagnosed by the neonatal screening program, the most common presenting complication is dactylitis, followed by recurrent episodes of pain and infection.

In older children cellulose acetate electrophoresis at an alkaline pH is most commonly used to determine hemoglobin subtype. The diagnosis can be confirmed using an alternative method such as HPLC fractionation or a DNA-based assay.

Diagnosis in adults

It is unusual for a person with sickle cell disease to reach adulthood without being aware of his/her diagnosis. The diagnosis should be suspected in a patient who presents with unexplained hemolysis, with or without intermittent episodes of pain (vaso-occlusive crises). Patients may also present with avascular necrosis, retinal hemorrhage, or leg ulcers.

The first steps in diagnosis include review of the peripheral blood smear, followed by hemoglobin electrophoresis and confirmatory diagnosis with HPLC fractionation. In patients where a rapid diagnosis is required, the sickle solubility test can be done by adding a reducing agent (that decreases the oxygen content of the sample), which will cause sickle polymers to form in any cell with sickle hemoglobin. The test will detect any sickle hemoglobin and so will be positive in patients with both sickle trait and sickle disease. Therefore, further confirmatory testing with HPLC fractionation or a DNA-based assay is needed.

Vaso-occlusive crisis

This common complication in children and adults causes severe pain and can be precipitated by cold, dehydration, infection, or ischemia - for example, muscle ischemia from strenuous exercise. The crisis may present as skeletal pain due to bone infarction or avascular necrosis, especially of the hip or shoulder.

The presentation of a skeletal vaso-occlusive crisis depends on the age of the patient because the events are thought to originate in bone marrow. In children, red marrow is present in all bones, including small bones of the hand, which is consistent with the clinical findings of dactylitis. In older children, marrow is most commonly found in the epiphyses, and in adults it is limited to axial skeletal bones - for instance, spine, pelvis, skull, and the most proximal portions of the femur and humerus. This fits clinically with the observed incidence of infarcts in long bones increasing with age, especially in the femoral/humeral head.[Figure caption and citation for the preceding image starts]: Avascular necrosis of the femoral head in patient with heterozygous (hemoglobin SC) sickle cell anemiaFrom: Davies SC, Oni L. BMJ. 1997 Sep 13;315(7109):656-60 [Citation ends].com.bmj.content.model.Caption@5b2171a3

Other presentations may mimic an acute abdomen or pneumonia (acute chest syndrome).

Acute chest syndrome

Acute chest syndrome is a frequent cause of death in both children and adults. It can be clinically indistinguishable from pneumonia. The patient presents with chest pain, fever, dyspnea, tachypnea, hypoxemia, and a new pulmonary infiltrate on chest x-ray. [Figure caption and citation for the preceding image starts]: Chest x-ray in acute chest syndromeFrom: Davies SC, Oni L. BMJ. 1997 Sep 13;315(7109):656-60 [Citation ends].com.bmj.content.model.Caption@921cda5

Other laboratory tests

Complete blood count (CBC) with a peripheral blood smear is used in testing older children and adults to evaluate the number and quality of red blood cells, hemoglobin content, and white blood cell count. CBC is useful in establishing a baseline for ongoing evaluation. It is widely available, inexpensive, and provides rapid results, but it is not diagnostic.

CBC should also be performed when a newborn screen is positive. It is important to remember that patients can present with vaso-occlusive pain and not have any change from baseline in their hemoglobin or reticulocyte count. [Figure caption and citation for the preceding image starts]: Red cells in sickle cell diseaseFrom the personal collection of Sophie Lanzkron, MD; used with permission [Citation ends].com.bmj.content.model.Caption@172f2a19

Iron studies help distinguish hemolytic anemia from iron deficiency anemia in all patients and can also detect iron overload from multiple transfusions.

Bacterial cultures of blood, sputum, urine, stool, and/or pus should be obtained in patients with fever and in those who appear toxic.

Imaging

Plain x-rays are used to confirm the presence of bone infarction. However, radiologic findings are localized to bones containing red marrow; therefore, the pattern of osseous changes is different in children and adults.

In children, red marrow is present in all bones including small bones of the hand, which is consistent with the clinical findings of dactylitis. In older children, red marrow is most commonly found in the epiphyses, and in adults it is limited to axial skeletal bones - for instance, spine, pelvis, skull, and the most proximal portions of the femur and humerus. This fits clinically with the observed incidence of infarcts in long bones increasing with age, especially in the femoral/humeral head.[Figure caption and citation for the preceding image starts]: Avascular necrosis of the femoral head in patient with heterozygous (hemoglobin SC) sickle cell anemiaFrom: Davies SC, Oni L. BMJ. 1997 Sep 13;315(7109):656-60 [Citation ends].com.bmj.content.model.Caption@4f287907

Chest x-ray is performed if the patient has respiratory symptoms, fever, or chest pain. [Figure caption and citation for the preceding image starts]: Age distribution of clinical problems in sickle cell diseaseFrom: Davies SC, Oni L. BMJ. 1997 Sep 13;315(7109):656-60 [Citation ends].com.bmj.content.model.Caption@4381fb5
